Compressor |
||||||
CFM |
190 | 300 | 400 | 750 | 900 | 1000 |
Working Pressure |
||||||
Bar |
7 | 7 | 7 | 7 | 7 | 8.6 |
PSI |
100 | 100 | 100 | 100 | 100 | 125 |
KPA |
700 | 700 | 700 | 700 | 700 | 860 |
Free Air Delivery |
||||||
L / S |
96 | 136 | 186 | 354 | 405 | 496 |
M3 / Min |
5.76 | 8.16 | 11.2 | 21.2 | 24.3 | 29.8 |
CFM |
190 | 300 | 392 | 750 | 900 | 1000 |
Fuel Tank Size |
||||||
LT |
80 | 175 | 175 | 350 | 400 | 540 |
Fuel Usage Per Hour |
||||||
Unload (Idle) |
4.5 | 6.3 | 9 | 16.5 | 17.8 | 29.0 |
Full Load |
9 | 14.6 | 20.6 | 31 | 38 | 52.3 |
Picking Hammers |
||||||
Make |
Atlas Copco | Blows / min | 2640 | |||
Model |
Tex 05P | Working Pressure | 6 Bar | |||
CFM Usage |
21.2 | Chuck Size | 19 x 50mm hex | |||
Weight |
6.5 kg | |||||
Chipping Hammers |
||||||
Make |
Atlas Copco | Blows / min | 1600 | |||
Model |
Tex 12 PSKL | Working Pressure | 6 Bar | |||
CFM Usage |
45.1 | Chuck Size | 22 x 82.5mm hex | |||
Weight |
12.5 kg | |||||
Chipping Steels |
||||||
|
|
Shank Size | Working Length | ||||
Moil |
22 mm x 82.5 mm | 380 mm | ||||
Chisel |
22 mm x 82.5 mm | 380 mm | ||||
Paving Breakers |
||||||
Make |
Atlas Copco | Blows / min | 1230 - 1500 | |||
Model |
Tex270, P60 & P90 | Working Pressure | 6 Bar | |||
CFM Usage |
+-76 | Shank Size | 32 x 160mm hex | |||
Weight |
30kg - 40kg | |||||
Breaker Steels |
||||||
|
|
Shank Size | Working Length | ||||
Moil |
32 x 160mm | 450mm | 1m AOR | |||
Chisel |
32 x 160mm | 450mm | 1m AOR | |||
Asphalt Cutter |
32 x 160mm | 115 x 150mm | ||||
Spade |
32 x 160mm | 450mm | ||||
Boulder Buster |
32 x 160mm | 450mm | ||||
Rock Drills |
||||||
Make |
SECO | Blows / min | 1900 | |||
Model |
S21 Blower | Working Pressure | 5 Bar | |||
CFM Usage |
105.96 | Chuck Size | 22 x 108mm hex | |||
Weight |
28.5 kg | |||||
Rock Drill Steels |
||||||
Type |
Shank Size | Working Length | ||||
Drill Steel |
22 mm x 108 mm | 0.8 m | ||||
| 1.2 m | ||||||
| 1.6 m | ||||||
